سرج ارستر تایپ B+C مدل MCF100-3+NPE+FS کد 5096987

Combination arrester, lightning current and surge arrester, type 1+2

• Protection level • For lightning protection equipotential bonding to VDE 0185-305 (IEC 62305)
• Lightning current arresting capacity to 100 kA (10/350), 3+NPE
• Line following current quenching 50 kA Ipeak, arrester backup fuse to 315 A gL/gG
• Fulfils the requirements of the VDEW directive and E VDE-AR-N 4100 for use in pre-meter area
• Encapsulated, non-extinguishing spark gap arrester for use in distributor housings

Application: Industrial systems and buildings with external lightning protection of the highest class I to IV.

توضیحات



توضیحات تکمیلی

وزن 935 کیلوگرم
